Computar VL0826S-MPZ 20MP 1" 8mm F2.6 LensConnect I²C C-Mount Lens

The Computar VL0826S-MPZ is an 8mm fixed focal length LensConnect machine vision lens designed for 1-inch format sensors and resolutions up to 20MP. This S-version uses I²C control for embedded and OEM integration, with motorized focus and iris adjustment for applications where manual lens access is limited.

With an F2.6 to F16 aperture range, 0.1m minimum working distance, and a wide 88.8° diagonal field of view on a 1-inch sensor, the VL0826S-MPZ is suited to machine vision, automated inspection, robotics, embedded vision, factory automation, and other high-resolution industrial imaging systems.

Key Features:

• 20MP optical resolution for 1-inch format sensors
• 8mm fixed focal length
• F2.6 to F16 aperture range
• LensConnect I²C interface for embedded system integration
• Motorized focus and iris control
• 0.1m to infinity focus range
• C-mount interface
• Wide 88.8° diagonal angle of view on 1-inch sensors
• Designed for high-resolution machine vision and factory automation

Applications:

• Machine vision and automated inspection
• Factory automation
• Robotics and embedded vision
• Warehouse and logistics imaging
• Quality control
• OEM camera systems

Technical Specifications
