USA Security Systems

LM28LF

Kowa LM28LF 28mm F-Mount Line Scan Lens

Kowa LM28LF 28mm F-Mount Line Scan Lens

SKU:LM28LF

Regular price $960.00 USD
Regular price Sale price $960.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Exceptional Precision for Your Vision Systems

Product Spec Sheet

In the realm of machine vision and industrial optics, Kowa LM28LF stands out as a pinnacle of precision and performance. Designed with meticulous attention to detail, this 28mm F-mount line scan lens caters to the most demanding imaging tasks with unparalleled clarity and accuracy.

Crafted for compatibility with sensors boasting a pixel size of 7.5μm or more, the Kowa LM28LF lens is optimized for 4K line scan cameras, delivering exceptional resolution across the entire imaging field. With its manual iris control and a versatile aperture range from f/2.8 to f/22, it offers precise control over light intake, ensuring optimal image quality in diverse lighting conditions.

The lens boasts remarkable specifications, including a resolution of 160 lp/mm at the center and 63 lp/mm at the corner, along with minimal distortion (-0.17%) and a generous back focus of 38.5mm. Its robust construction, encompassing a temperature range from -10°C to +50°C, ensures reliable performance even in challenging environments.

From quality inspection in manufacturing facilities to precise imaging in factory automation, the applications of the Kowa LM28LF span a wide spectrum of industrial and machine vision tasks. With its superior optics and exceptional imaging capabilities, it empowers businesses to achieve unmatched levels of accuracy and efficiency in their vision systems.

Features:

  • Optimized for 4K line scan cameras
  • Manual iris control with an aperture range from f/2.8 to f/22
  • High resolution: 160 lp/mm at the center, 63 lp/mm at the corner
  • Minimal distortion: -0.17%
  • Wide temperature range: -10°C to +50°C

Applications:

  • Quality inspection
  • Factory automation
  • Manufacturing processes
  • Precision imaging
  • Optical metrology
