USA Security Systems

LM35VM42

Kowa LM35VM42 2" ø32mm 50MP 2" ø32mm 50MP Lens Compatible With Sony IMX342, CMOSIS CMV12000, CMV20000 & CMV50000

Kowa LM35VM42 2" ø32mm 50MP 2" ø32mm 50MP Lens Compatible With Sony IMX342, CMOSIS CMV12000, CMV20000 & CMV50000

SKU:LM35VM42

Regular price $1,103.00 USD
Regular price Sale price $1,103.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Revolutionize Industrial Imaging with Kowa LM35VM42 Lens

Product Spec Sheet

Transform your industrial imaging capabilities with the Kowa LM35VM42 lens. Crafted with precision optics and designed for compatibility with sensors like Sony IMX342, CMOSIS CMV12000, CMV20000, and CMV50000, this 2" ø32mm 50MP lens offers unparalleled clarity and resolution. Its fixed focal length and manual iris control ensure precise image capture tailored to your specific needs.

With a resolution of 160 lp/mm at the center and 100 lp/mm at the corner, this lens delivers exceptional detail across the frame. Whether you're inspecting manufacturing processes, monitoring quality control, or implementing machine vision systems, the Kowa LM35VM42 lens provides the reliability and performance required for demanding industrial applications.

Engineered for versatility, this lens is suitable for sensors with a pixel size of 3.1μm or more, ensuring compatibility with a wide range of imaging systems. Additionally, its wide temperature range of -10°C to +50°C allows for reliable operation in diverse industrial environments.

Experience the difference with Kowa LM35VM42 lens and unlock new possibilities in industrial imaging, from automated inspection and robotics guidance to object recognition and production line monitoring. Gain a competitive edge with superior image quality and precision optics tailored to your industrial needs.

Features:

  • Compatible with Sony IMX342, CMOSIS CMV12000, CMV20000 & CMV50000 sensors
  • Fixed focal length with manual iris control
  • High resolution: 160 lp/mm at center, 100 lp/mm at corner
  • Precision optics for exceptional clarity
  • Suitable for sensors with pixel size of 3.1μm or more
  • Wide temperature range: -10°C to +50°C

Applications:

  • Automated inspection
  • Quality control
  • Robotics guidance
  • Object recognition
  • Production line monitoring
