TAMRON M112FM16 – Industrial Lens | C-mount 1/1.2" 16mm

*Please note tariff fee is included in price*

SKU focus: M112FM16 (TAMRON industrial lens) — sold by USA Security Systems.

Why choose the TAMRON M112FM16?

• Focal: 16mm
• Aperture: F0.1
• Image format: 1/1.2" sensor coverage
• Mount: C-mount
• Optics: Aspheric optics

Best-fit applications

• Industrial inspection (AOI), metrology, and quality control
• Factory automation, robotics guidance, and machine vision
• Sorting, labeling, barcode/ID reading, and measurement
• Security and intelligent imaging where consistent optics matter

Search terms this page targets

M112FM16, “TAMRON M112FM16 lens”, and “16mm 1/1.2" lens”.

Enhance Your Vision with Tamron M112FM16 16mm F/2.0 Aspherical Mega-Pixel Lens

Tamron is renowned in the machine vision and industrial imaging sectors for delivering high-quality lenses like the M112FM16 16mm F/2.0 Aspherical Mega-Pixel Fixed-Focal Lens. This C-mount lens is optimized for compatibility with 1/1.2" imagers, offering exceptional clarity and accuracy in image capture. The lens features a versatile aperture range from F/2.0 to F/16, ensuring adaptability to varying light conditions. With a compact design and weighing just 51g, it's ideal for integration into automated systems where space and weight are critical.

Applications of the Tamron M112FM16 span across industrial automation, quality control, robotics, and inspection systems. Its manual focus and iris adjustments, coupled with a minimum focusing distance of 0.1m, provide precise control over image capture. The lens also boasts minimal TV distortion (-0.56%) and operates reliably in temperatures ranging from -20°C to +60°C, making it suitable for diverse environmental conditions.

Features:

• 16mm focal length with F/2.0 aperture
• Aspherical lens design for high-resolution imaging
• Manual focus and iris with lock for precise adjustments
• Lightweight and compact (51g)
• Wide operating temperature range (-20°C to +60°C)

Applications:

• Industrial automation
• Quality control
• Robotics
• Inspection systems

Imager Size	1/1.2"
Mount	C
Focal Length	16mm
Aperture Range	F/2.0-16
Field Of View Angle (H/V)	1/1.2"  [4:3] 37.4° x 28.4°   [16:9] 40.5° x 22.3° 2/3"     [4:3] 31.0° x 23.4°   [16:9] 33.7° x 19.2°
Focusing Range	0.1m ~ INF (Recommended Shooting Distance: 0.3m)
Focus	With manual lock
Iris	With manual lock
Filter Size	M27 P=0.5mm
Compatible Wavelengths	Visible light range
Weight	51g
TV Distortion	-0.56%
Weight	51g
Operating Temperature	-20°C ~ +60° C
