TAMRON M112FM25 – Industrial Lens | 1/1.2" 25mm

*Please note tariff fee is included in price*

SKU focus: M112FM25 (TAMRON industrial lens) — sold by USA Security Systems.

Why choose the TAMRON M112FM25?

• Focal: 25mm
• Aperture: F1.8
• Image format: 1/1.2" sensor coverage
• Optics: Aspheric optics

Best-fit applications

• Industrial inspection (AOI), metrology, and quality control
• Factory automation, robotics guidance, and machine vision
• Sorting, labeling, barcode/ID reading, and measurement
• Security and intelligent imaging where consistent optics matter

Search terms this page targets

M112FM25, “TAMRON M112FM25 lens”, and “25mm 1/1.2" lens”.

Unveiling the Tamron M112FM25 25mm F/1.8 Aspherical Mega-Pixel Fixed-Focal Lens

Tamron, renowned for its optical excellence, presents the M112FM25 25mm F/1.8 Aspherical Mega-Pixel Fixed-Focal Lens, designed for precision in industrial and machine vision environments. With a wide aperture range of 1.8 to 16 and an imager size compatibility of 1/1.2", this lens ensures exceptional clarity and detail, crucial for high-resolution imaging tasks. Its aspherical design minimizes distortion and aberrations, maintaining image integrity across various lighting conditions.

Ideal for applications requiring meticulous inspection and measurement, the Tamron M112FM25 offers versatile performance with manual focus and iris adjustments, complemented by a robust build suitable for temperatures ranging from -20°C to +60°C. Weighing just 54g, it's optimized for ease of integration and longevity in demanding industrial settings.

Features:

• Aspherical lens design
• Wide aperture range: F/1.8 - 16
• Manual focus and iris with lock
• Lightweight at 54g
• Temperature-resistant (-20°C to +60°C)

Applications:

• Automated inspection systems
• Quality control processes
• Robotics and automation
• Object recognition
• Surveillance and security

Imager Size	1/1.2"
Mount	C
Focal Length	25mm
Aperture Range	F/1.8 to F/16
Angle of View (4:3)	1/1.2": 24.1° x 18.2°, 2/3": 19.9° x 15.0°
Angle of View (16:9)	1/1.2": 26.2° x 15.0°, 2/3": 21.7° x 12.3°
Focus Range	0.1m to ∞ (Recommended: 0.3m)
Focus Access	With manual lock
Iris	With manual lock
Filter Thread Diameter	M27 P=0.5mm
Compatible Wavelengths	Visible light range
Distortion	-0.09%
Mass	54g
Operating Temperature Range	-20℃ to +60℃
