TAMRON M117FM06 – Industrial Lens | 1/1.7" 6mm

*Please note tariff fee is included in price*

SKU focus: M117FM06 (TAMRON industrial lens) — sold by USA Security Systems.

Why choose the TAMRON M117FM06?

• Focal: 6mm
• Aperture: F6
• Image format: 1/1.7" sensor coverage
• Resolution class: 6MP+
• Optics: Aspheric optics

Best-fit applications

• Industrial inspection (AOI), metrology, and quality control
• Factory automation, robotics guidance, and machine vision
• Sorting, labeling, barcode/ID reading, and measurement
• Security and intelligent imaging where consistent optics matter

Search terms this page targets

M117FM06, “TAMRON M117FM06 lens”, and “6mm 1/1.7" lens”.

Discover the Tamron M117FM06 6mm F/2.4 Aspherical Mega Pixel Fixed-Focal Lens

Tamron is renowned for its precision optics, catering specifically to industrial and machine vision applications. The Tamron M117FM06 6mm F/2.4 Aspherical Mega Pixel Fixed-Focal Lens exemplifies their commitment to quality and innovation. This lens is designed for use with 1/1.7-inch imagers and is compatible with 6MP cameras, offering a focal length of 6mm and an aperture range from F/2.4 to F/16. Its aspherical design ensures minimal distortion (-1.02% TV distortion), making it ideal for applications requiring high image fidelity and clarity. With manual focus and iris adjustments, plus a robust build suitable for temperatures ranging from -20°C to +60°C, the Tamron M117FM06 excels in demanding environments. Industries benefitting from this lens include automotive inspection, electronics manufacturing, and pharmaceutical production, where precise image capture is critical for quality control and automation. Partner with us to integrate Tamron’s cutting-edge lens technology into your vision systems for enhanced performance and reliability.

Features:

• Aspherical design for minimal distortion
• Manual focus and iris adjustments with locks
• Lightweight and durable construction (50g)
• Wide operating temperature range: -20°C to +60°C
• Compatible with 1/1.7-inch imagers and 6MP cameras

Applications:

• Automotive inspection
• Electronics manufacturing
• Pharmaceutical production

Imager Size	1/1.7"
Mount Type	C
Focal Length	6mm
Aperture Range	F/2.4 - F/16
Field of View Angle	1/1.7": 65.0° x 50.5°1/1.8": 64.2° x 44.9°1/2": 56.5° x 43.4°1/3": 43.4° x 32.9°
Focus Range	0.1m - ∞ (Recommended Shooting Distance: 0.3m)
Operation	Focus: Manual w/lockIris: Manual w/lock
Filter Size	M34 P=0.5
Wave Length	Visible Light
TV Distortion	-1.02%
Weight	50g
Operating Temperature	-20°C - +60°C
