USA Security Systems

M117FM16

Tamron M117FM16 16mm F/2.4 Manual 6 Mega Pixel Lens w/lock - C-Mount

Tamron M117FM16 16mm F/2.4 Manual 6 Mega Pixel Lens w/lock - C-Mount

SKU:M117FM16

Regular price $164.00 USD
Regular price Sale price $164.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Discover the Tamron M117FM16 16mm F/2.4 Manual 6 MP Lens

Tamron is renowned for its precision-crafted lenses tailored for industrial and machine vision applications. The Tamron M117FM16 16mm F/2.4 Manual 6 MP Lens exemplifies their commitment to quality and innovation. Designed for use with 6 MP cameras and featuring a robust C-mount, this lens offers exceptional clarity and accuracy across diverse industrial settings.

Engineered with manual focus and iris controls, the Tamron M117FM16 allows precise adjustments to focal points and light intake, ensuring optimal imaging performance. Its compact build and lightweight design (40g) make it versatile for installations where space and weight considerations are critical. The lens supports an aperture range from F/2.4 to F/16, accommodating various lighting conditions.

Ideal applications include automated inspection, quality control, robotics, and surveillance systems where high-resolution imaging is imperative. The Tamron M117FM16 enhances productivity and reliability in industrial environments by delivering sharp, distortion-free images with minimal TV distortion (-0.1%). From manufacturing to security, Tamron lenses are trusted for their durability, superior optics, and compatibility with leading machine vision systems.

Features:

  • 16mm focal length
  • Manual focus and iris with lock
  • Lightweight design (40g)
  • Wide aperture range (F/2.4 - F/16)
  • Compatible with 6 MP cameras

Applications:

  • Automated inspection systems
  • Quality control processes
  • Robotics and automation
  • Surveillance and security systems

M117FM16 Spec Sheet

Imager Size 1/1.7"
Mount C
Focal Length 16mm
Aperture Range 2.4–16
Angle of View (1/1.7") 26.1° x 19.7°
Angle of View (1/1.8") 25.7° x 17.4°
Angle of View (1/2") 22.3° x 16.8°
Angle of View (1/3") 16.8° x 12.6°
Focus Range 0.1m to ∞ (Recommended: 0.3m)
Focus With manual lock
Iris With manual lock
Filter Thread Diameter M27 P=0.5mm
Compatible Wavelengths Visible light range
Distortion -0.1%
Mass 40g
Operating Temperature Range -20℃ to +60℃
