TAMRON M13VG2713IR – Industrial Lens | 1/2.7" 2.7–13mm Auto Iris IR

*Please note tariff fee is included in price*

SKU focus: M13VG2713IR (TAMRON industrial lens) — sold by USA Security Systems.

Why choose the TAMRON M13VG2713IR?

• Focal: 2.7–13mm
• Image format: 1/2.7" sensor coverage
• Iris: Auto Iris
• IR: IR / Day-Night
• Optics: Aspheric optics

Best-fit applications

• Industrial inspection (AOI), metrology, and quality control
• Factory automation, robotics guidance, and machine vision
• Sorting, labeling, barcode/ID reading, and measurement
• Security and intelligent imaging where consistent optics matter

Search terms this page targets

M13VG2713IR, “TAMRON M13VG2713IR lens”, and “2.7–13mm 1/2.7" lens”.

Enhance Your Vision Systems with Tamron's M13VG2713IR Mega-Pixel Vari-Focal Lens

Tamron, a renowned name in the lens industry, presents the M13VG2713IR, a 1/2.7" 2.7-13mm F/1.4 aspherical mega-pixel vari-focal lens designed for high-performance machine vision and industrial applications. This lens is built to deliver exceptional image quality with a wide aperture range of F/1.4 to 360, ensuring excellent light intake and superior image clarity even in low-light conditions. The lens features a CS mount, manual focus and zoom with locks, and a DC auto iris, making it versatile and easy to integrate into various systems.

With a wide horizontal and vertical field of view, ranging from 125.1°x66.1° at the widest setting to 26.7°x15.2° at the narrowest, the Tamron M13VG2713IR is ideal for applications requiring detailed surveillance and inspection. It supports visible light to near-infrared wavelengths, making it suitable for both day and night operations. Additionally, its robust construction ensures reliable performance in extreme temperatures, from -20°C to +60°C.

Ideal for use in security systems, factory automation, and quality control, the Tamron M13VG2713IR enhances the capabilities of any vision system, providing crisp, clear, and detailed images essential for accurate analysis and monitoring.

Features:

• High-resolution aspherical mega-pixel lens
• 2.7-13mm vari-focal length
• Wide aperture range (F/1.4 - 360)
• CS mount compatibility
• Manual focus and zoom with locks
• DC auto iris for dynamic light conditions
• Supports visible light to near-infrared wavelengths
• Durable design for extreme temperatures

Applications:

• Security camera systems
• Factory automation
• Quality control inspections
• Robotics vision systems
• Traffic monitoring and control
• Agricultural monitoring
• Medical imaging devices

Imager Size	1/2.7"
Mount Type	CS
Focal Length	2.7 - 13mm
Aperture Range	F/1.4 - F/360
Field of View Angle (1/2.7")	Wide: 125.1° x 66.1°, Tele: 26.7° x 15.2°
Field of View Angle (1/3")	Wide: 101.1° x 73.9°, Tele: 22.3° x 16.8°
Focusing Range	0.3m - ∞
Operation	Focus: Manual w/lock, Zoom: Manual w/lock, Iris: DC Auto IRIS
Back Focal Distance	8.42 mm (in air)
Wave Length	Visible Light - Near Infrared
Operating Voltage	OPEN: 4V, CLOSE: 0.5V
Weight	90g ± 5g
Operating Temperature	-20°C - +60°C
