TAMRON MA23F08V – Industrial Lens | C-mount 2/3" 8mm
TAMRON MA23F08V – Industrial Lens | C-mount 2/3" 8mm
SKU:MA23F08V
Couldn't load pickup availability
*Please note tariff fee is included in price*
SKU focus: MA23F08V (TAMRON industrial lens) — sold by USA Security Systems.
Why choose the TAMRON MA23F08V?
- Focal: 8mm
- Aperture: F08
- Image format: 2/3" sensor coverage
- Mount: C-mount
- Optics: Aspheric optics
Best-fit applications
- Industrial inspection (AOI), metrology, and quality control
- Factory automation, robotics guidance, and machine vision
- Sorting, labeling, barcode/ID reading, and measurement
- Security and intelligent imaging where consistent optics matter
Search terms this page targets
MA23F08V, “TAMRON MA23F08V lens”, and “8mm 2/3" lens”.
Tamron MA23F08V 2/3" 8mm F/2.4 Fixed-Focal Lens
Tamron is renowned in the industrial optics industry for its precision-engineered lenses, exemplified by the MA23F08V 2/3" 8mm F/2.4 Fixed-Focal Lens. Designed specifically for machine vision applications, this lens offers exceptional compatibility with high-resolution sensors such as the IMX536, IMX546, and IMX566.
Its C-mount configuration ensures versatility across various industrial setups, providing a focal length of 8mm and an aperture range from F/2.4 to F/16. With a lightweight yet robust build weighing only 84g, the Tamron MA23F08V operates seamlessly in temperatures ranging from -20°C to +60°C.
Tamron MA23F08V lens delivers precision and reliability for industrial machine vision. Explore high compatibility and sharp imaging today!
Features:
- 2/3" format, 8mm focal length
- F/2.4 - F/16 aperture range
- Lightweight at 84g
- C-mount with M34 P=0.5mm filter size
- Manual focus and iris with lock
Applications:
- Automated inspection systems
- Quality control in manufacturing
- Robotics and motion analysis
- Object recognition and tracking
- Semiconductor inspection
Imager Size
2/3"
Mount
C
Focal Length
8mm
Aperture Range
F/2.4 to F/16
Angle of View
(horizontal x vertical)
2/3" (1:1): 53.1° x 53.1°
2/3" (4:3): 58.9° x 45.5°
2/3"(16:9): 63.2° x 37.7°
1/1.8" (4:3): 47.4° x 36.4°
1/2" (4:3): 44.3° x 33.7°
1/3" (4:3): 33.7° x 25.5°
Focus Range
0.1m to ∞ (Recommended Shooting Distance: 0.3m)
How to Use Focus
With manual lock
Iris
With manual lock
Filter Thread Diameter
M34 P=0.5mm
Compatible Wavelengths
Visible light range
Distortion
-0.6%
Mass
84g
Operating Temperature Range
-20℃ to +60℃
(horizontal x vertical)
2/3" (4:3): 58.9° x 45.5°
2/3"(16:9): 63.2° x 37.7°
1/1.8" (4:3): 47.4° x 36.4°
1/2" (4:3): 44.3° x 33.7°
1/3" (4:3): 33.7° x 25.5°
