VS Technology VS-LTC3.5-80CO-45/S Line Scan Telecentric Lens

Advanced Telecentric Imaging Lens for Precision Inspection

Product Spec Sheet

Elevate your imaging capabilities with the VS Technology VS-LTC3.5-80CO-45/S Lens, an exceptional upgrade for LTC4/5/6/7-28/F models. Boasting a telecentric design and a 45mm image circle, this lens delivers unparalleled image quality and versatility for various industrial applications. With a pixel resolution of 2.5um (2001p/mm), it ensures detailed and accurate imaging for precise inspection tasks.

One of the standout features of this lens is its low color chromatic aberration, guaranteeing crisp and true-to-life images across the entire field of view. Whether you're conducting wafer inspection for micro LED production or inspecting electric devices with AOI (Automated Optical Inspection), this lens excels in capturing fine details with utmost clarity.

Designed to meet the demands of modern manufacturing environments, the VS-LTC3.5-80CO-45/S Lens is indispensable for industries requiring high-resolution imaging, such as semiconductor manufacturing, electronics manufacturing, and precision engineering. Its compatibility with sensors ranging from 21mm to 45mm in diameter further enhances its versatility, making it a valuable asset for quality control and inspection tasks.

Features:

• M52 Mount
• Telecentric design with 45mm image circle
• Low color chromatic aberration for true-to-life images
• Pixel resolution of 2.5um (2001p/mm)
• Ideal for wafer inspection and electric device AOI
• Compatible with sensors ranging from 21mm to 45mm
• Suitable upgrade for LTC4/5/6/7-28/F models

Applications:

• Wafer inspection
• Micro LED production (Mini LED 200-100um > microLED 10-50um)
• Electric device inspection
• Automated Optical Inspection (AOI)
• Quality control
• Semiconductor manufacturing
